3 Getting Started
34 Pulse Laser Station NPL-302 Series Instruction Manual
Table 3.2 summarizes the functions of the NPL-302 keys.
Table 3.2 Key functions
Key Function Details
Turns the instrument on or off. page 28
Illumination key. Turns the backlight on or off.
Provides access to the 2-switch window if held down for
one second.
page 38
Displays the MENU screen. page 115
Changes the key input mode between alphanumeric
and numeric if pressed when you are in a PT or CD
field.
Activates Qcode mode if pressed when you are In the
Basic Measurement Screen (BMS).
page 41
Records measured data, moves on to the next screen,
or confirms and accepts the entered data in input mode.
You have the option to record the measurement as a CP
record instead of an SS record, if you hold this key down
for one second in the Basic Measurement Screen
(BMS).
The instrument outputs the current measurement data
(PT, HA, VA, and SD) on the COM port if you press this
key in the BMS or in a Stakeout observation screen.
(The Data Rec settings must be set to COM.)
page 103
Returns to the previous screen.
In numeric or alphanumeric mode, deletes input.
Starts distance measurement, using the measure mode
settings for the [MSR1] key.
Displays measurement mode settings, if held down for
one second.
page 58
