3.10 Basic Configuration
The basic 7705 SAR interface configuration must include the following tasks:
• identify chassis slot (step in activating the IOM)
• specify card type (step in activating the IOM)
• identify adapter card (MDA) slot
• specify adapter card type (mda-type) (must be an allowed adapter card type)
• specify adapter card mode (mda-mode) (supported on the 4-port DS3/E3
Adapter card, the 16-port T1/E1 ASAP Adapter card version 2, the 32-port T1/E1
ASAP Adapter card, the 10-port 1GigE/1-port 10GigE X-Adapter card, the 4-port
OC3/STM1 / 1-port OC12/STM4 Adapter card, and the Integrated Services
card)
• identify specific port to configure
The following example displays some card and port configurations on the
7705 SAR-8.
ALU-1>config# card 1
ALU-1>config>card# info
#--------------------------------------------------
echo "Card Configuration"
#--------------------------------------------------
card 1
card-type iom-sar
mda 1
mda-type a6-em
exit
mda 2
mda-type a4-oc3
exit
mda 3
mda-type a16-chds1
exit
mda 4
mda-type a4-chds3
mda-mode cem-atm-ppp
exit
mda 5
mda-type a8-eth
exit
mda 6
mda-type a2-choc3
exit
exit
Note: The 7705 SAR-18 displays similar output with the exception being that the MDA
number goes from 1 to 12 and from X1 to X4 (for XMDA cards).
