3.1.2.4 Channelized Adapter Card Support
The following cards and modules support channelization down to the DS0 level:
• 16-port T1/E1 ASAP Adapter card
• 32-port T1/E1 ASAP Adapter card
• 12-port Serial Data Interface card
• 6-port E&M Adapter card
• 2-port OC3/STM1 Channelized Adapter card
• 4-port DS3/E3 Adapter card
• 8-port Voice & Teleprotection card
• 8-port FXO Adapter card
• 6-port FXS Adapter card
• 4-port T1/E1 and RS-232 Combination module
On the 16-port T1/E1 ASAP Adapter card, 32-port T1/E1 ASAP Adapter card,
2-port OC3/STM1 Channelized Adapter card, and 4-port DS3/E3 Adapter card (DS3
ports only), and on the T1/E1 ports of the 4-port T1/E1 and RS-232 Combination
module, up to 24 channel groups are supported on a DS1 circuit and up to 32 channel
groups on an E1 circuit.
The 12-port Serial Data Interface card supports a single channel group on a
channelized V.35 circuit, RS-232 (also known as EIA/TIA-232) circuit, or X.21 circuit.
The RS-232 ports on the 4-port T1/E1 and RS-232 Combination module also support
a single channel group on a channelized RS-232 circuit.
The 6-port E&M Adapter card supports a single channel group on a channelized
E&M voice interface.
The 8-port Voice & Teleprotection card supports a single channel group on a
channelized G.703 (codirectional) circuit, an IEEE C37.94 teleprotection interface
(TPIF) circuit, FXS circuit, or FXO circuit.
The 8-port FXO Adapter card supports a single channel group on an FXO circuit.
Third Generation 6-port Ethernet 10Gbps Adapter card
7705 SAR-X
Table 2 Ethernet Adapter Card, Module, and Platform Generations
Generation Card, Module, and Platform
