3.1.3.10 Microwave Link
A microwave link can be configured as a virtual port object on a 7705 SAR-8 or
7705 SAR-18 in order to provide a basic microwave connection or the Microwave
Awareness (MWA) capability to an MPR-e node
For more information, see Microwave Link.
3.1.3.11 CLI Identifiers for Adapter Cards, Modules and Platforms
On the CLI, the adapter cards are referred to as MDAs. A port is identified using the
format slot/mda/port, where slot identifies the IOM card slot ID (always 1), mda
identifies the physical slot in the chassis for the adapter card, and port identifies the
physical port on the adapter card; for example, 1/5/1. Adapter cards are configured
at the card and port level.
On the fixed platforms, no configuration is required at the adapter card level in order
to provision the ports.
On the CLI for the 7705 SAR-A, the slot/mda identifier for T1/E1 ports is 1/2 and for
Ethernet ports is 1/1. T1/E1 ports are identified as 1/2/1 through 1/2/8 for the variant
of the chassis with T1/E1 ports. Ethernet ports for both variants of the 7705 SAR-A
are identified as 1/1/1 through 1/1/12.
Ring generation 16 Hz (the default)
20 Hz
25 Hz
Signaling type 3600 Private Line Automatic Ringdown (PLAR) (if Mu-Law
or A-Law is used)
1511 PLAR (if A-Law is used)
1511 Profile1 (if A-Law is used)
3600 Loop Start (LS) (if Mu-Law is used; this is the default)
3600 Remote Extension (RE) (if A-Law is used; this is the
default)
Transmission level point
(TLP)
Rx: –7 dB to 0 dB (1-dB increments; the default is –3 dB)
Tx: –4 dB to +3 dB (1-dB increments; the default is 0 dB)
Table 5 Configuration Options for the 6-port FXS Adapter Card
Configuration Supported Options
