Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 585
fdb
Syntax fdb [mac ieee-address] [port port-id] [all]
Context show>mda>ring
Description This command displays the forwarding database (FDB) for the specified MAC address or ring
port, or all FDBs associated with the specified ring adapter card.
Parameters ieee-address — displays the FDB associated with the specified MAC address
port-id — displays the FDB associated with the specified port, where the port is a ring port
or the v-port
all — displays all FDBs associated with the ring adapter card
Output The following output is an example of FDB information, and Table 45 describes the fields.
Output Example
*A:7705:Dut-A# show mda 1/2 ring fdb port 1/11/1
=======================================
Ring MDA Forwarding Database for 1/11/1
=======================================
Total Access dropped Packets/
Octets
The number of access in-profile and out-of-profile
packets/octets dropped
Aggregated Security Statistics See Table 40 and Table 41
Aggregated IP Transport Statistics
IP Transport Queue Statistics
Network Ingress Queue
Forwarded
Dropped
The number of IP-Transport subservice network ingress
queued packets and bytes that were forwarded and
dropped
Access Ingress Queue
Forwarded
Dropped
The number of IP-Transport subservice access ingress
queued packets and bytes that were forwarded and
dropped
Serial Socket Queue Statistics
Access Ingress Queue
Forwarded
Dropped
The number of serial raw socket access ingress queued
packets and bytes that were forwarded and dropped
Table 44 Show MDA Aggregate Statistics Output Fields (Continued)
Label Description
