Transceiver Digital Diagnostic Monitoring (DDM), Externally Calibrated
SFP manufacturers specifications guidelines contained in
specification SFF-8472, for the following:
• temperature (C)
• supply voltage (V)
• Tx bias current (mA)
• Tx output power (dBm)
• Rx optical power (avg dBm)
For the above categories, the following values are shown:
• Value is the current measured value of each variable
• High Alarm is the measurement of Value that will
cause a DDM High Alarm to be output
• High Warn is the measurement of Value that will
cause a DDM High Warning Alarm to be output
• Low Warn is the measurement of Value that will cause
a DDM Low Warning Alarm to be output
• Low Alarm is the measurement of Value that will
cause a DDM Low Alarm to be output
If alarms/warnings are raised, there will be an "!" in the
output
Traffic Statistics
Octets Input/Output The total number of octets received and transmitted on the
port
Packets Input/Output The number of packets, delivered by this sublayer to a
higher (sub) layer, which were not addressed to a multicast
or broadcast address at this sublayer. The total number of
packets that higher-level protocols requested be
transmitted, and which were not addressed to a multicast
or broadcast address at this sublayer, including those that
were discarded or not sent.
Table 58 Show Specific Port Output Fields (GigE Port with Optical SFP)
Label Description
