Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 641
Output Example
*A:ALU-1># show port 1/2/1
===============================================================================
SONET/SDH Interface
===============================================================================
Description : OC-3 SONET/SDH
Interface : 1/2/1 Speed : oc3
Admin Status : up Oper Status : up
Physical Link : Yes Loopback Mode : none
Single Fiber Mode : No
Ing. Pool % Rate : 100 Egr. Pool % Rate : 100
APS Group : none APS Role : none
Clock Source : node Framing : sonet
Last State Change : 11/24/2009 13:05:56 Port IfIndex : 46170112
Last Cleared Time : N/A DDM Events : Enabled
J0 String : 0x01 Section Trace Mode : byte
Rx S1 Byte : 0x00 (stu) Rx K1/K2 Byte : 0x00/0x00
Tx S1 Byte : 0x00 (stu) Tx DUS/DNU : Disabled
Rx J0 String (Hex) : 01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Cfg Alarm : loc lrdi lb2er-sf slof slos
Alarm Status :
BER SD Threshold : 6 BER SF Threshold : 3
Hold time up : 500 milliseconds
Hold time down : 0 milliseconds
Transceiver Type : SFP
Model Number : 3HE00034AAAA02 ALU IPUIAEXDAB
TX Laser Wavelength: 1310 nm Diag Capable : yes
Connector Code : LC Vendor OUI : 00:00:00
Manufacture date : 2009/04/25 Media : SONET/SDH
Serial Number : 1XX200083926037
Part Number : FTM3101CSL2iAL
Optical Compliance : OC3-SR-MM
Link Length support: 2000m for 50u MMF; 2000m for 62.5u MMF
SFP Sync-E Capable : n/a
===============================================================================
Transceiver Digital Diagnostic Monitoring (DDM), Externally Calibrated
===============================================================================
Value High Alarm High Warn Low Warn Low Alarm
-------------------------------------------------------------------------------
Temperature (C) +36.6 +100.0 +95.0 -35.0 -40.0
Supply Voltage (V) 3.28 3.80 3.63 2.97 2.70
Unknown proto discards
input/output
For packet-oriented interfaces, the number of packets
received at the interface that were discarded because of
an unknown or unsupported protocol. For character-
oriented or fixed-length interfaces that support protocol
multiplexing, the number of transmission units received
at the interface that were discarded because of an
unknown or unsupported protocol. For any interface that
does not support protocol multiplexing, this counter will
always be 0.
Table 60 Show Specific Port Output Fields (Serial Port) (Continued)
Label Description
