Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 649
Table 63 Show Specific Port Output Fields (FXO Voice Port)
Label Description
Voice Physical Interface
Description A text description of the port
Interface The port ID displayed in the slot/mda/port format
Port IfIndex The interface's index number, which reflects its
initialization sequence
Admin Status up: the administrative state is up
down: the administrative state is down
Oper Status up: the operating state is up
down: the operating state is down
Physical Link Yes: a physical link is present
No: a physical link is not present
Type The type of voice interface (fxo)
Signaling Type Loop Start (ls) or Loop Calling Disconnect Clear (lcdc)
TLP Rx The receive transmission level point value for the port
Line Balance nominal or 800
TLP Tx The transmit transmission level point value for the port
Port Statistics
Packets Input/Output The number of packets, delivered by this sublayer to a
higher (sub) layer, which were not addressed to a
multicast or broadcast address at this sublayer. The total
number of packets that higher-level protocols requested
be transmitted, and which were not addressed to a
multicast or broadcast address at this sublayer, including
those that were discarded or not sent.
Discards Input/Output The number of inbound/outbound packets chosen to be
discarded to possibly free up buffer space
