7705 SAR Interfaces
670
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
Port Control Statistics
Ingress Queue CTL The number of forwarded packets and octets, and the
number of dropped packets, for the ingress control
queue. For access ports, this statistic applies only to
Ethernet cards. For network ports, this statistic applies to
all adapter cards.
Egress Queue CTL The number of forwarded packets and octets, and the
number of dropped packets, for the egress control queue.
For access ports, this statistic applies only to Ethernet
cards. For network ports, this statistic applies to all
adapter cards.
Ethernet CFM Statistics
Cfm LbmRx The number of LBMs received
Cfm LbReplyTx The number of LBRs transmitted
Cfm LbmDropped The number of LBMs dropped
Num Bn Rate Chng The number of times that the port egress rate is
dynamically changed based on Bandwidth Notification
(BN) messages
Note: not every bandwidth change indicated by a BNM
triggers a port egress rate change
Last BnRateChng The time that the port egress rate was last changed
based on a BNM
Valid BnmRx The number of valid BN messages received
Last Valid BnmRx The time that the last valid BNM was received
Invalid BnmRx The number of invalid BN messages received
BnmOutOfRangeBW The number of BN messages received with a requested
bandwidth that was out of range
Ethernet-like Medium Statistics
Alignment Errors The total number of packets received that had a length
(excluding framing bits, but including FCS octets) of
between 64 and 1518 octets, inclusive, but that had either
a bad Frame Check Sequence (FCS) with an integral
number of octets (FCS Error) or a bad FCS with a non-
integral number of octets
Table 67 Show Port Detail Output Fields (Ethernet, Access Mode)
Label Description
