Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 675
DSL Output Example
*A:ALU-1># show port 1/3/2 detail
===============================================================================
DSL Interface
===============================================================================
Description : XDSL Bonding
Interface : 1/3/2 US Rate : 98017 kbps
PortType : XDSL DS Rate : 200016 kbps
Admin State : up BondingType : efm
Oper State : up BondingState : up
NtrDslLineID : 1 AtmVpi : 8
NtrLockedStatus : lock AtmVci : 35
NtrStdDev : 100 NtrMaxError : 56 ns
NtrMinError : 10 ns NtrSampleClkPeri*: 28 ns
NtrErrHsty (*28 ns): 00 ff 00 00 00 00 00 00 00 00 00 00 00 00 00 00
:00000000000000000000000001000000
:0000000000000000000000000000ff00
:0000000000000000000000000000ff00
:00000000000000000001000001000000
:00000000000000000000000000ff0000
:00000000000001000000000000000001
:00000000000000000000ff0000000000
:00000000000000000000ff0000000100
:00000000000000000000000000000000
:000000ff000000000000000000000000
:00000100000000ff0000000000000000
:000000000000000100000000ff0000ff
:000000ff0000000000000000000000ff
:00000000000000010000000100000000
:0000000000000000000000ff000000ff
IfIndex : 39911424 MTU : 1518
Last State Change : 06/02/2011 18:54:33 Hold time up : 0 seconds
Last Cleared Time : N/A Hold time down : 0 seconds
Configured Mode : access Encap Type : 802.1q
Dot1Q Ethertype : 0x8100
Ing. Pool % Rate : 100 Egr. Pool % Rate : 100
Unshaped Egress Queue For the specified unshaped egress queue, the of number
packets and octets that are:
• In Profile forwarded/dropped
• Out Profile forwarded/dropped
Total Egress from all Shaped
and Unshaped Queues
For all shaped and unshaped queues, the total number of
egress packets and octets that are:
• In Profile forwarded/dropped
• Out Profile forwarded/dropped
Egress Queue CTL The number of forwarded packets and octets, and the
number of dropped packets, for the egress control queue.
Table 68 Show Port Detail Output Fields (Ethernet, Network Mode)
Label Description
