7705 SAR Interfaces
716
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
Cfg Alarm The type of alarms to be logged and reported for the port
Alarm Status The current alarm state
Hold time up The hold-timer value for link-up event dampening
Hold time down The hold-timer value for link-down event dampening
Sync. Status Msg. The setting of SSM: enabled or disabled
Tx DUS/DNU The setting of tx-dus: enabled or disabled
Ssm-bit The Sa bit that carries the quality level value: Sa4 to Sa8
Rx Quality Level The SSM QL value received on the interface
Tx Quality Level The SSM QL value transmitted on the interface
Framing The DS1 framing to be used for the port
Oper Status up: the port is operationally up
down: the port is operationally down
Clock Source loop-timed: the link recovers the clock from the received
data stream
node-timed: the link uses the internal clock when
transmitting data
adaptive: clocking is derived from the incoming
pseudowire packets
differential: clocking is derived from a common clock
compared to differential clock recovery data in the RTP
header in the TDM PW overhead
Clock Sync State The current state of the clock recovery function
Channel IfIndex The channel interface index number
In Remote Loop Indicates whether incoming remote loopback is enabled
Egr. Sched. Pol The egress scheduling policy
BER SD Threshold The configured value of the BER SD threshold
BER SF Threshold The configured value of the BER SF threshold
Traffic Statistics
Octets Input/Output The total number of octets received and transmitted on
the port
Table 73 Show Port Detail Output Fields (TDM DS1 Interface) (Continued)
Label Description
