Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 739
Cfg Alarm Indicates the alarms configured
Last State Change The last time the operational status of the port changed
state
Chan Grp IfIndex The channel group index number
Channel IfIndex The channel interface index number
Configured Mode network: the port is configured for transport network use
access: the port is configured for service access
Encap Type The encapsulation type for the channel group (atm, cem,
ipcp, ppp-auto, hdlc, or cisco-hdlc)
Admin MTU The configured MTU
Oper MTU The negotiated size of the largest packet that can be sent
on the port or channel specified in octets
Scramble Indicates whether payload scrambling is enabled on
channel groups (only applicable if encap type is atm)
Hold time up The hold-timer value for link-up event dampening
Hold time down The hold-timer value for link-down event dampening
Physical Link Yes: a physical link is present
No: a physical link is not present
Bundle Number The number assigned to the multilink bundle
Idle Cycle Flags The value transmitted by the DS0, DS1, or E1 interface
during idle cycles
Clock Source loop-timed: the link recovers the clock from the received
data stream
node-timed: the link uses the internal clock when
transmitting data
adaptive: clocking is derived from the incoming
pseudowire packets
Payload Fill Type The payload type to be transmitted when the circuit
emulation service is not operational or temporarily
experiences underrun conditions (only valid for
CESoPSN services)
Payload Pattern The user-defined pattern transmitted if the payload fill
type is pattern
Table 76 Show Port Channel Group Output Fields (Continued)
Label Description
