Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 759
FE Tx Num Failures : 0 FE Rx Num Failures : 0
Tx ICP Cell count : 0 Rx ICP Cell count : 0
Error ICP Cells Total : 0 Rx Lost ICP Cells Total : 0
Relative Link Delay : 0
===============================================================================
*A:ALU-1#
Table 83 Show Port IMA Link Output Fields
Label Description
State Information
Transmit Link Identifier The identifier of the IMA link used to transmit data
Receive Link Identifier The identifier of the IMA link used to receive data
Near Rx Failure State The failure state of the near-end receive link
Far End Rx Failure State The failure state of the far-end receive link
Near End Tx State The state of the near-end transmit link
Near End Rx State The state of the near-end receive link
Far End Tx State The state of the far-end transmit link
Far End Rx State The state of the far-end receive link
Link Test State The state of the link test procedure: Enabled or Disabled
Rx Test Pattern The received test pattern in an IMA link loopback operation
(0 to 255)
TC Sublayer Information
TC Alarm State The alarm state for the traffic class of the IMA link
HEC Errors (Dropped) The number of HEC errors resulting in dropped packets
Number OCD Events The number of OCD events
HEC Errors (Fixed) The number of HEC errors fixed
Statistical Information
Num Violations The number of violations (path, line, code, and length)
NE Severely Err. Seconds The number of near-end severely errored seconds
NE Unavail. Seconds The number of seconds that the near end has been
unavailable
NE Tx Unused Seconds The number of seconds that the near-end transmit link has
been unused
