7705 SAR Interfaces
772
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
Table 88 Show Port Output Fields (TDM Codirectional or TPIF)
Label Description
TDM Data Physical Interface
TDM Data Interface
Description A text description of the port
Interface The port ID displayed in the slot/mda/port format
Port IfIndex The port interface's index number, which reflects its
initialization sequence
Admin Status up: the administrative state is up
down: the administrative state is down
Oper Status up: the operating state is up
down: the operating state is down
Physical Link yes: a physical link is present
no: a physical link is not present
Type The type of interface: codirectional or TPIF
Clock Source loop-timed: the link recovers the clock from the received
data stream
node-timed: the link uses the internal clock when
transmitting data
adaptive: clocking is derived from the incoming
pseudowire packets
differential: clocking is derived from a common clock
compared to differential clock recovery data in the RTP
header in the TDM PW overhead
Timing 8khz Indicates whether 8-kb/s timing on a codirectional
interface is enabled or disabled
Last State Change The last time the operational status of the port changed
state
Channel IfIndex The channel interface index number
Loopback The loopback mode for the channel: internal-analog,
internal-digital, or none
Cfg Alarm The type of alarms to be logged and reported for the port
Alarm Status The current alarm state
