7705 SAR Interfaces
776
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
dsl
Syntax dsl [efm-oam | line-num]
Context show>port>dsl
Description This command displays DSL port information
Parameters efm-oam — displays EFM-OAM information for DSL ports
line-num — displays DSL line information
Values 1 to 8
Output The following output is an example of DSL port information and Table 90 describes the fields.
Output Example
SHDSL port information
Oper Status up: the port is operationally up (communication with the
GNSS receiver is established, the self-test has passed,
and the antenna status is OK)
down: the port is operationally down (any of the up
conditions have not been met)
Elev. Mask Angle Specifies the configured elevation angle below which
satellites are ignored. The default elevation mask angle is
10°.
Visible Satellites Specifies the number of satellites that the GNSS receiver
should see at the current time. This number can be 0 if
the GNSS receiver has not yet downloaded an almanac,
even if Used Satellites is more than 0.
Five or more satellites must be in view of the GNSS
receiver antenna at all times when the receiver is in the
process of obtaining a position fix, and these satellites
must be above the configured elevation mask angle.
Used Satellites Specifies the number of tracked satellites
Latitude Specifies the latitude of the GNSS antenna
Longitude Specifies the longitude of the GNSS antenna
Altitude (m MSL) Specifies the altitude of the GNSS antenna above mean
sea level, in meters
Table 89 Show Port Output Fields (GNSS) (Continued)
Label Description
