Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 823
Admin Status Up: the bundle is administratively up
Down: the bundle is administratively down
Minimum Links The minimum number of links that must be active for a
bundle to be active. If the number of links drop below the
given minimum, then the multilink bundle will transition to
an operation down state.
Total Links The total number of active member links configured for
this bundle
Red Diff Delay The maximum acceptable differential delay for individual
circuits within this multilink bundle. If the delay exceeds
this threshold, a trap is issued.
Red Diff Delay Act The action that will be taken on the MLPPP bundle once
the Red Diff Delay is exceeded
Short Sequence Indicates whether the MLPPP bundle uses short (12 bit)
sequence numbers instead of the default 24-bit
sequence number
Oper MTU The negotiated size of the largest packet that can be sent
on the port or channel, specified in octets
Mode network: the port is configured for transport network use
access: the port is configured for service access
Type The bundle type
Oper Status The operational port status of a member link
Bundle IfIndex The bundle’s interface index number, which reflects its
initialization sequence
Active Links The total number of active links for the bundle
Yellow Diff Delay The yellow warning threshold for the differential delay for
members within a multilink bundle
MRRU The configured maximum frame size that can be
reconstructed from multilink fragments
Oper MRRU The operating maximum frame size that can be
reconstructed from multilink fragments
Bandwidth The bandwidth configured for this MLPPP bundle in kb/s
Table 113 Show Multilink Bundle MLPPP Detail Fields (Continued)
Label Description
