Interface Configuration Guide Standards and Protocol Support
Edition: 01 3HE 11011 AAAC TQZZA 879
Notes:
1. Performance Class 1
2. Performance Class 1 (Class 2 with Optics interfaces only)
3. Performance Class 2
4. Zone A; Performance Class 1
5. Zone A; Performance Class 1 (Class 2 with Optics interfaces only)
6. Zone B; Performance Class 1
7. Zone A; Performance Class 2
8. With the exception of DC surges
Table 122 EMC Regulatory and Customer Standards Compliance
Standard Title Platform
SAR-X
SAR-A
SAR-Ax
SAR-M
SAR-8
SAR-18
SAR-H
SAR-Hc
SAR-W
SAR-Wx
IEC 61000-4-2 Electrostatic discharge immunity test ✓✓✓✓✓✓✓✓✓✓
IEC 61000-4-3 Radiated electromagnetic field immunity
test
✓✓✓✓✓✓✓✓✓✓
IEC 61000-4-4 Electrical fast transient/burst immunity
test
✓✓✓✓✓✓✓✓✓✓
IEC 61000-4-5 Surge immunity test ✓✓✓✓✓✓✓✓✓✓
IEC 61000-4-6 Immunity to conducted disturbances ✓✓✓✓✓✓✓✓✓✓
IEC 61000-4-8 Power frequency magnetic field
immunity test
✓ ✓ ✓✓✓✓
IEC 61000-4-9 Pulse Magnetic field immunity test ✓ ✓ ✓✓✓✓
IEC 61000-4-10 Damped Oscillatory Magnetic Field ✓ ✓ ✓✓✓✓
IEC 61000-4-11 Voltage dips, short interruptions and
voltage variations immunity tests
✓
✓
1
✓
1
✓
1
✓
1
✓
1
✓
✓
1
✓✓
IEC 61000-4-12 Oscillatory wave immunity test ✓ ✓ ✓✓✓✓
IEC 61000-4-16 Conducted immunity 0 Hz - 150 kHz ✓ ✓ ✓✓✓✓
IEC 61000-4-17 Ripple on d.c. input power port immunity
test
✓ ✓ ✓✓✓✓
IEC 61000-4-18 Damped oscillatory wave immunity test ✓ ✓ ✓✓✓✓
IEC 61000-4-29 Voltage dips, short interruptions and
voltage variations on d.c. input power
port immunity tests
✓ ✓ ✓✓✓✓
IEC 61000-3-2 Limits for harmonic current emissions
(equipment input current <16A per
phase)
✓
✓
1
✓
1
✓
1
✓
1
✓
1
✓
✓
1
✓✓
