Wall mounting for the device
Set for mounting the device, separate from the
motor (e.g. to a wall).
Model SK TIE4-WMK-…
( Section
2.1.3 "Wall mounting")
Wall mounting for SK TU4-…
modules
Set for mounting a technology unit, SK TU4-...,
separate from the device (e.g. to a wall).
Model SK TIE4-WMK-TU
( Section
3.2.2 "External technology units
SK TU4-… (module attachment)")
Pos: 34 .10 /A nleitu ngen/ Elektr onik /FU und St art er/1. Al lgemei nes/ Liefer umfa ng/Li eferu mfang Zubeh ör_08_ Schal ter un d Potis [B U 0180, 0200] @ 6\mod_1430916492063_388.docx @ 216022 @ @ 1
Switches and potentiometers
Switch / potentiometer unit
(L – OFF – R / 0 – 10 V)
Customer unit for attaching to the device for
ease of control of the device using switches and
potentiometers
Model SK CU4-POT
 Section
3.2.1 "Internal customer interfaces
SK CU4-… (installation of modules)"
ATEX potentiometer
(0 – 10 V)
Potentiometer with ATEX capability for attaching
to the device for ease of control of the device
Model SK ATX-POT
 Section 3.2.1 "Internal customer interfaces
SK CU4-… (installation of modules)"
Potentiometer
(0 – 10 V)
Potentiometer for attaching to the device for
ease of control of the device
Model SK TIE4-POT
 Section
3.2.1 "Internal customer interfaces
SK CU4-… (installation of modules)"
Switch
(L – OFF – R)
Switch for attaching to the device for simple
control of the device
Model SK TIE4-SWT
 Section
3.2.2 "External technology units
SK TU4-… (module attachment)"
Maintenance switch
(0 – I)
Technology unit for attaching to the device or
alternatively for wall mounting (wall mounting kit
required) for safely insulating the device from the
AC power supply.
Model SK TU4-MSW- …
 Section
3.2.2 "External technology units
SK TU4-… (module attachment)"
Setpoint adjuster
(L – 0 – R / 0 – 100 %)
Technology unit for attaching to the device or
alternatively for wall mounting (wall mounting kit
required) for simple control of the device using
buttons and potentiometers, including power
supply for generating a 24 V DC control voltage.
Model SK TU4-POT- …
 Section
3.2.2 "External technology units
SK TU4-… (module attachment)"
