1.8.6 Adapter Unit type code
SK TIE4-WMK-1 (-C- …)
Further details (depending on type)
Details (depending
on type)
C = IP66, EX = ATEX, PBR = PROFIBUS –
Signal cable, …
Type (selection): WMK-1 = Wall mounting kit (version
1
),
M12 = M12 plug connector for connection of signal cables,
HAN = Harting – System plug connector for power connection
Connection extension
Pos: 65 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/Lei st ung - Baugrößen- Zuor dnu ng [ SK 2xx E] @ 1\mod_1342517155776_388.docx @ 32 866 @ 2 @ 1
1.9 Power rating / Motor size
Size
Mains / Power category SK 2xxE
1~ 110 - 120 V
1)
1~ 200 – 240 V
2)
3~ 200 – 240 V 3~ 380 – 500 V
Size 1
0.25 ... 0.37 kW
0.25 ... 0.55 kW
0.37 ... 1.1 kW
0.55 ... 2.2 kW
Size 2
0.55 ... 0.75 kW
0.75 ... 1.1 kW
1.5 ... 2.2 kW
3.0 ... 4.0 kW
Size 3
-
-
3.0 ... 4.0 kW
5.5 ... 7.5 kW
Size 4 - - 5.5 ... 11.0 kW 11.0 … 22.0 kW
1) only available as SK 2x5E model
2) only available as SK 2x0E model in size 1
Pos: 66 /Anlei tung en/ Ele ktr oni k/FU und Star ter /1. Al lge mei nes/ Aus führ ung i n der Sc hutz art IP5 5 / I P66 [S K 1 xxE, 2x xE] @ 1\mod_1341482558691_388.docx @ 29774 @ 255 @ 1
1.10 Version in protection class IP55, IP66
The SK 2xxE is available in IP55 (standard) or IP66 (optional). The additional modules are available in
protection classes IP55 (standard) or IP66 (optional).
A protection class that differs from the standard (IP66) must always be specified in the order when
ordering!
There are no restrictions or differences to the scope of functionality in the protection classes that have
been mentioned. The type designation is extended accordingly in order to distinguish between the
protection classes.
e.g. SK 2xxE-221-340-A-C
Information
Cable laying
For all versions, care must be taken that the cables and the cable glands at least comply with the protection class
of the device and the attachment regulations and are carefully matched. The cables must be inserted so that
water is deflected away from the device (if necessary use loops). This is essential to ensure that the required
protection class is maintained.
IP55 version:
The IP55 version is the standard version. In this version, the two installation types motor mounted
(fitted onto the motor) and close coupled (fitted to the wall bracket) are available. All adapter units,
technology units and customer units are also available for this version.
