NORDAC FLEX (SK 200E ... SK 235E) – Users Manual for Frequency Inverters
270 BU 0200 en-3118
Pos: 74 6 /Anlei tung en/El ektr onik/FU und Star ter/8 . Zus atzinfor mati one n/Motor date n Kennl inien [SK 1x0E , SK 2x0E ]/87Hz Kennli nie [SK 1x 0E, SK 2xxE] @ 2\mod_1347450038971_388.docx @ 46305 @ 3 @ 1
8.8.2 87 Hz characteristic curve (only 400V devices)
( Variation 01:17)
The 87 Hz -
characteristic represents an
extension of the speed adjustment range with
a constant motor nominal torque. The
following points must be met for realisation:
•
Motor delta connection with a motor
winding for 230/400 V
•
Frequency inverter with an operating
voltage 3~400 V
•
Output current of frequency inverter must
be greater than the delta current of the
motor used (ref. value  frequency inverter
power ≥ √3 motor power)
87 Hz characteristic curve (4-pole motor)
0
0,2
0,4
0,6
0,8
1
1,2
0 10 20 30 40 50 60 70 80 90 100
Frequenz / Hz
M/Mn
M/M
N
P/P
N
0 1445 2890
Frequency
[Hz]
Speed
[1/min]
Figure 39: 87 Hz characteristic curve
In this configuration, the motor used has a rated operating point at 230 V/50 Hz and an extended
operating point at 400 V/ 87 Hz. This increases the power of the drive by a factor of √3 The nominal
torque of the motor remains constant up to a frequency of 87 Hz. Operation of a 230 V winding with
400 V is totally uncritical as the insulation is designed for test voltages of > 1000 V.
Pos: 74 7 /Anlei tung en/El ektr onik/FU und Star ter/8 . Zus atzinfor mati one n/Motor date n Kennl inien [SK 1x0E , SK 2x0E ]/87Hz Kennli nie_Tabellen [SK 2xxE] @ 6\mod_1429275790438_388.docx @ 212313 @ @ 1
NOTE: The following motor data applies to standard motors with 230V/400 V windings.
Motor
(IE1)
SK …
Frequency
inverter
SK 2xxE-…
M
N
*
[Nm]
Parameterisation data of frequency inverter
F
N
[Hz]
n
N
[min-1]
I
N
[A]
U
N
[V]
P
N
[kW]
cos Ï•
Y/Δ
R
St
[Ω]
71S/4
550-340-A
1.73
50
1365
1.3
230
0.25
0.79
Δ
39.9
71L/4
750-340-A
2.56
50
1380
1.89
230
0.37
0.71
Δ
22.85
80S/4 111-340-A 3.82 50 1385 2.62 230 0.55 0.75 Δ 15.79
80L/4
151-340-A
5.21
50
1395
3.52
230
0.75
0.75
Δ
10.49
90S/4
221-340-A
7.53
50
1410
4.78
230
1.1
0.76
Δ
6.41
90L/4
301-340-A
10.3
50
1390
6.11
230
1.5
0.78
Δ
3.99
100L/4
401-340-A
14.6
50
1415
8.65
230
2.2
0.78
Δ
2.78
100LA/4 551-340-A 20.2 50 1415 11.76 230 3.0 0.78 Δ 1.71
112M/4
751-340-A
26.4
50
1430
14.2
230
4.0
0.83
Δ
1.11
132S/4
112-340-A
36.5
50
1450
20.0
230
5.5
0.8
Δ
0.72
132M/4
152-340-A
49.6
50
1450
26.8
230
7.5
0.79
Δ
0.46
132MA/4
182-340-A
60.6
50
1455
32.6
230
9.2
0.829
Δ
0.39
160MA/4 222-340-A 72.2 50 1455 37 230 11 0.85 Δ 0.36
* at rated point
