NORDAC FLEX (SK 200E ... SK 235E)Users Manual for Frequency Inverters
30 BU 0200 en-3118
Pos: 47 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/Z ulas sung en/ UL und C SA Zul ass ung _T eil 1 [all ge mei n] @ 7\ mod_1432204309954_388.docx @ 221458 @ 2 @ 1
1.7 UL and CSA approval
File No. E171342
Categorisation of protective devices approved by the UL according to United States Standards for the
inverters described in this manual is listed below with essentially the original wording. The
categorisation of individually relevant fuses or circuit breakers can be found in this manual under the
heading Electrical Data”. All devices include motor overload protection.
( section 7.2 "Electrical data")
Pos: 48 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/Z ulas sung en/ UL und C SA Zul ass ung _T eil 2 _Erg änz u ng - Gruppenabsicherung [SK 2xxE, SK 1xxE, -FD S] @ 7\mod_1433943179219_388.doc x @ 2 238 41 @ @ 1
Information
Group fuse protection
The devices can basically be protected as a group via a common fuse (details in the following). The adherence of
the total currents and the use of the correct cables and cable cross-sections must be taken into account when
doing this. If the device or devices is/are being installed close to the motor, this also applies to the motor cable.
Pos: 49 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/Z ulas sung en/ UL und C SA Zul ass ung _T eil 2_Ergänzung [SK 1xxE, SK 2xxE, SK 5xxE, -FDS] @ 7\ mod_1433943883212_388.docx @ 223873 @ 5 @ 1
UL / CSA conditions according to the report
Pos: 50 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/Z ulas sung en/ UL und C SA Zul ass ung _T eil 3 _ori gin al_ Wor tla ut [ SK 2 xxE] @ 6\mod_1427210838785_0.docx @ 209531 @ @ 1
Information
"Integral solid state short circuit protection does not provide branch circuit protection. Branch circuit protection
must be provided in accordance with manufacturer instructions, the National Electric Code and any additional
local codes."
“Use 80°C Copper Conductors Only." (size 1 3)
Use 60/75°C copper field wiring conductors.” (size 4)
„These products are intended for use in a pollution degree 2 environment“
“The device has to be mounted according to the manufacturer instructions.”
“For NFPA79 applications only
Information
Internal Break Resistors (PTCs)
Alternate - internal brake resistors, optional for drives marked for USL only (not for Canada), Unlisted Component
NMTR3, manufactured by Getriebebau:
Usage Cat. No.
1
FS1-112,
FS2-112,
FS1-123,
FS2-123
BRK-100R0-10-L or- M alternate PLR or PLRC100.61.41 100R 100W
2
FS1-323,
FS2-323
BRK-200R0-10-L or- M alternate PLR or PLRC100.61.41 200R 100W
3
FS1-340
BRK-400R0-10-L or- M alternate PLR or PLRC100.61.41 400R 100W
4 FS3-323 BRM-100R0-10-L or- M alternate PLR or PLRC200.70.51 100R 200W
5 FS2-340,
FS3-340
BRM-200R0-10-L or- M alternate PLR or PLRC200.70.51 200R 200W
6 -551-323 1x BRQ-47R0-10-L or- M alternate PLR or PLRC300.70.61 47R 300W
7
-751-323
1x BRQ-47R0-10-L or- M alternate PLR or PLRC300.70.61 47R 300W
8
-112-323
2x BRQ-47R0-10-L or- M alternate PLR or PLRC300.70.61 47R 300W
9 -112-340 1x BRQ-100R-10-L or- M alternate PLR or PLRC300.70.61 100R 300W
10 -152-340 1x BRQ-100R-10-L or- M alternate PLR or PLRC300.70.61 100R 300W
11
-182-340
2x BRQ-100R-10-L or- M alternate PLR or PLRC300.70.61 100R 300W
12
-222-340
2x BRQ-100R-10-L L or- M alternate PLR or PLRC300.70.61 100R 300W
