2.4.2.2 Motor cable (U, V, W, PE)
The motor cable may have a total length of 100 m if it is a standard cable type (take EMC into
consideration). If a screened motor cable is used, or if the cable is laid in a well-earthed metal conduit,
the total length should not exceed 20 m (connect cable shield to PE, on both sides).
For multiple motor operation the total motor cable length consists of the sum of the individual cable
lengths.
Pos: 14 9 /Anlei tung en/El ektr onik/FU und Star ter/1 . Allg emei nes/Sic herh eits- und Ins tall ations hinwei se un d Warn- Gefahrenhinweise/neu/Warn- und Gefahrenhinweise/ACHTUNG - Schal ten a m Ausgang [FU] @ 19 \mod_1511537843960_388.docx @ 2372764 @ @ 1
NOTICE
Output switching
Switching a motor cable under load causes an impermissibly high load on the device. Components in the power
section may be damaged and destroyed either immediately or in the long term.
• Only switch the motor cable when the frequency inverter no longer pulses, i.e. the device must be in the state
"ready for switch-on" or "switch-on block".
Pos: 15 0 /Anlei tung en/El ektr onik/FU und Star ter/2 . Mon tage un d Install atio n/Ele ktrisc her Ans chlus s/SK 1xxE, SK 2 xxE, S K xxxE-FDS/L eist u ngstei l/ Ele ktri sch er An schl uss L eist ungs tei l_T eil 3 - M otork abel_0 3 [SK 1 x0E, SK 2 xxE, SK 2x xE-FDS] @ 7\mod_1434533958731_388.docx @ 226371 @ @ 1
Information
Synchronous motors or multiple motor operation
If synchronous machines or several motors are connected in parallel to a device, the frequency inverter must be
switched over to linear voltage/frequency characteristic curves,  P211 = 0 and P212 = 0.
For multiple motor operation the total motor cable length consists of the sum of the individual motor cable lengths.
Pos: 15 1 /Anlei tung en/El ektr onik/FU und Star ter/2 . Mon tage un d Install atio n/Ele ktrisc her Ans chlus s/SK 1xxE, SK 2 xxE, S K xxxE-FD S/L eist ung stei l/ Elek tris cher An schl uss L eist ungs teil _T eil 3 - Br emswiderstand_01 [SK 1x0E, SK 2xxE] @ 7\mod_1434537485678_388.docx @ 226595 @ 4 @ 1
2.4.2.3 Braking resistor (+B, -B) – (from size 1)
The terminals +B/ -B are intended for the connection of a suitable braking resistor. A short screened
connection should be selected.
Pos: 15 2 /Anlei tung en/El ektr onik/FU und Star ter/1 . Allg emei nes /Sic herh eits - und I nstall atio nshin weise un d Warn- Gefahrenhinweise/neu/Warn- und Gefahrenhinweise/VORSICHT - Hei ße O ber fläc he n (B rems wi ders tan d) @ 1 9\mod_1511280417222_388.docx @ 2372139 @ @ 1
CAUTION
Hot surfaces
The braking resistor and all other metal components can heat up to temperatures above 70°C.
• Danger of injury due to local burns on contact.
• Heat damage to adjacent objects
Allow sufficient cooling time before starting work on the product. Check the surface temperatures with suitable
measuring equipment. Maintain an adequate distance to adjacent components or provide protection against
contact.
