Nord Drivesystems NORDAC FLEX SK 210E Series User Manual

NORDAC FLEX (SK 200E ... SK 235E) – Users Manual for Frequency Inverters
146 BU 0200 en-3118
Pos: 32 8 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ P2xx Motord aten / Kennlini enpar ame ter @ 0\mod_1327588046860_388.docx @ 7838 @ 3 @ 1
5.2.3 Motor data / Characteristic curve parameters
Parameter
{factory setting}
Setting value / Description / Note Supervisor Parameter set
Pos: 32 9 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P2 00-P2 99/Par amet er P200 – Motorl ist e - Allgemeiner Teil [BU0180, BU0200, BU0500, SK 2xxE-FDS] @ 6 \mod_1421165097687_388.docx @ 19899 1 @ @ 1
P200
Motor list
(Motor list)
P
0 ... 73
{ 0 }
The factory settings for the motor data can be changed with this parameter. The factory setting in
parameters P201...P209 is a 4-pole IE1 - DS standard motor with the nominal FI power setting.
By selecting one of the possible digits and pressing the ENTER key, all motor parameters
(P201…P209) are adjusted to the selected standard power. The basis for the motor data is a 4-pole
DS standard motor. The motor data for NORD IE4 motors can be found in the final section of the
list.
NOTE:
As P200 returns to = 0 after the input confirmation, the control of the set motor can be implemented
via parameter P205.
Information
IE2/IE3 Motors
If IE2/IE3 motors are used, after selecting an IE1 motor (P200) the motor data in P201 to P209
must be adapted to the data on the motor type plate.
Pos: 33 0 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 ...) /P200- P299 /Para meter P200 – Mo torl ist e - DIP - Sch alter [SK 2 xxE] @ 2\mod_1346931673014_388.docx @ 42255 @ @ 1
NOTE: If DIP switches S1:7 (50/60Hz operation (chapter
4.3.2.2)
) are changed over, the
relevant nominal motor data is reloaded in accordance with the FI nominal power
from list P200.
Pos: 33 1 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter auf list ung (P0 00 . ..) /P2 00- P299/ Para meter P2 00 – Motor list e [SK 2xxE, SK 5 xxE] @ 6\mod_1421165368263_388.docx @ 199023 @ @ 1
