2.3.3 Brake resistor assignments
The brake resistors provided by NORD are directly tailored to the individual devices. However, when
external brake resistors are being used, it is usually possible to select between 2 or 3 alternatives.
Inverter ID Internal External braking resistor
1)
SK 2xxE-… Braking resistor Preferred Alternative Alternative
250-112-O
SK BRI4-1-100-100
SK BRx4-1-100-100
SK BRx4-2-100-200
370-112-O
SK BRI4-1-100-100
SK BRx4-1-100-100
SK BRx4-2-100-200
550-112-O
SK BRI4-1-100-100
SK BRx4-1-100-100
SK BRx4-2-100-200
750-112-O
SK BRI4-1-100-100
SK BRx4-1-100-100
SK BRx4-2-100-200
250-123-A
SK BRI4-1-100-100
SK BRx4-1-100-100
SK BRx4-2-100-200
370-123-A
SK BRI4-1-100-100
SK BRx4-1-100-100
SK BRx4-2-100-200
550-123-A
SK BRI4-1-100-100
SK BRx4-1-100-100
SK BRx4-2-100-200
750-123-A
SK BRI4-1-100-100
SK BRx4-1-100-100
SK BRx4-2-100-200
111-123-A
SK BRI4-1-100-100
SK BRx4-1-100-100
SK BRx4-2-100-200
250-323-A
SK BRI4-1-200-100
SK BRx4-1-200-100
SK BRx4-2-200-200
SK BRx4-2-100-200
370-323-A
SK BRI4-1-200-100
SK BRx4-1-200-100
SK BRx4-2-200-200
SK BRx4-2-100-200
550-323-A
SK BRI4-1-200-100
SK BRx4-1-200-100
SK BRx4-2-200-200
SK BRx4-2-100-200
750-323-A
SK BRI4-1-200-100
SK BRx4-1-200-100
SK BRx4-2-200-200
SK BRx4-2-100-200
111-323-A
SK BRI4-1-200-100
SK BRx4-1-200-100
SK BRx4-2-200-200
SK BRx4-2-100-200
151-323-A
SK BRI4-1-200-100
SK BRx4-1-200-100
SK BRx4-2-200-200
SK BRx4-2-100-200
221-323-A
SK BRI4-1-200-100
SK BRx4-1-200-100
SK BRx4-2-200-200
SK BRx4-2-100-200
301-323-A
SK BRI4-2-100-200
SK BRx4-2-100-200
401-323-A
SK BRI4-2-100-200
SK BRx4-2-100-200
551-323-A
SK BRI4-3-047-300
SK BRx4-3-050-450
751-323-A
SK BRI4-3-047-300
SK BRx4-3-050-450
112-323-A
SK BRI4-3-023-600
SK BRx4-3-050-450
550-340-A
SK BRI4-1-400-100
SK BRx4-1-400-100
SK BRx4-2-200-200
750-340-A
SK BRI4-1-400-100
SK BRx4-1-400-100
SK BRx4-2-200-200
111-340-A
SK BRI4-1-400-100
SK BRx4-1-400-100
SK BRx4-2-200-200
151-340-A
SK BRI4-1-400-100
SK BRx4-1-400-100
SK BRx4-2-200-200
221-340-A
SK BRI4-1-400-100
SK BRx4-1-400-100
SK BRx4-2-200-200
301-340-A
SK BRI4-1-400-100
SK BRx4-1-400-100
SK BRx4-2-200-200
401-340-A
SK BRI4-1-400-100
SK BRx4-1-400-100
SK BRx4-2-200-200
551-340-A
SK BRI4-2-200-200
SK BRx4-2-200-200
751-340-A
SK BRI4-2-200-200
SK BRx4-2-200-200
112-340-A
SK BRI4-3-100-300
SK BRx4-3-100-450
152-340-A
SK BRI4-3-100-300
SK BRx4-3-100-450
182-340-A
SK BRI4-3-050-600
SK BRx4-3-100-450
222-340-A
SK BRI4-3-050-600
SK BRx4-3-100-450
1) SK BRx4-: versions: SK BRE4-, SK BRW4-, SK BREW4-
Table 7: Assignment of brake resistors to frequency inverter
