2 Assembly and installation
BU 0200 en-3118 51
Pos: 99 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 2. M o ntag e un d Ins tall ati on/M o ntag e/M otor mo ntag e - Standard [SK 1xxE, SK 2xxE]/Montage externe Technologieboxen SK TU4 … [SK 1xxE / SK 2xxE] @ 1\mod_1342698159577_388.docx @ 35426 @ 3 @ 1
2.2.3 Installation of external technology units SK TU4-… (attachment)
The technology units SK TU4-…(-C) require a connection unit SK TI4-TU-…(-C). This is the only way
to create a closed functional unit. This can be attached to the device or installed separately by means
of the optional SK TIE4-WMK-TU wall-mounting kit. In order to provide reliable operation, cable
lengths of more than 20 m between the technology unit and the device must be avoided.
Information
Detailed installation information
A detailed description can be found in the documents for the connection unit concerned.
Connection unit Document
SK TI4-TU-BUS
TI 275280000
SK TI4-TU-BUS-C TI 275280500
SK TI4-TU-NET
TI 275280100
SK TI4-TU-NET-C
TI 275280600
SK TI4-TU-MSW TI 275280200
SK TI4-TU-MSW-C
TI 275280700
