1.8.4 Type code for option modules
Pos: 60 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/T ypens chl üss el/ Ty pensc hlü ssel O pti onsb aug rup pen – TU4 und CU4_02 (Bus,IO) [SK 1x0E, SK 2xxE] @ 9\mod_1444894597440_388.docx @ 2 49908 @ 5 @ 1
For bus module or I/O extension
SK TU4-CAO (-C-M12)
M12 system connector: only TU4, alternative to terminals
IP protection class:
Standard = IP55, C = "coated" = IP66
Option type:
CAO = CANopen, PBR = Profibus,
ECT = EtherCAT®, DEV = DeviceNet,
IOE = Internal I/O extension
Group: CU = Customer interface, TU = Technology box
(...) Options, only implemented if required.
Pos: 61 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/T ypens chl üss el/ Ty pensc hlü ssel O pti onsb aug rup pen – TU4 und CU4_03 (Net) [SK 1xxE, SK 2xxE] @ 9\mod_1444894608978_388.docx @ 249940 @ 5 @ 1
For "PotiBox" power supply or potentiometer modules
SK TU4-24V-123-B (-C)
IP protection class: Standard = IP55,
C = "coated" = IP66
Radio interference filter: B = Class B (C1)
Mains connection: 123 = 1~ 230V, 140 = 1~ 400V
Option type:
24V = 24V power supply
, POT = Potentiometer/switch
module
Option series:
TU4 = external technology unit (attachment),
CU4 = internal customer unit (installation)
(...) Options, only implemented if required.
Pos: 62 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/T ypens chl üss el/ Ty pensc hlü ssel Tec h nolog ie box - Anschl usseinheit [ SK 1xxE, S K 2xxE] @ 1\mod_1341921261385_388.docx @ 31167 @ 3 @ 1
1.8.5 Type code, connection unit for technology unit
SK TI4-TU-BUS (-C)
IP protection class:
Standard = IP55
, C = "coated" IP66
Suitable
device types:
NET = Mains option module (e.g. TU4-24V-…)
BUS = Bus option module (e.g. CANopen:
TU4-CAO
Group: TU = Technology unit
Device series: SK TI4 = Connection unit SK TI4
(...) Options, only implemented if required.
