NORDAC FLEX (SK 200E ... SK 235E) – Users Manual for Frequency Inverters
164 BU 0200 en-3118
Pos: 41 6 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ P4xx Steuer klem men @ 0\mod_1327678262854_388.docx @ 9027 @ 3 @ 1
5.2.5 Control terminals
Parameter
{factory setting}
Setting value / Description / Note Supervisor
Parameter
set
Pos: 41 7 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P4 00-P4 99/Par amet er P400 – Fkt. S oll wert eing ang [SK 2x0E ] @ 2\ mod_1346931795708_388.docx @ 42329 @ @ 1
P400 [-01]
...
[-09]
Function Setpoint inputs
(Function of setpoint inputs)
SK 2x0E
P
0 ... 36
{ [-01] = 1 }
{ [-02] = 0 }
{ [-03] = 0 }
{ [-04] = 0 }
{ [-05] = 1 }
{ [-06] = 0 }
{ [-07] = 1 }
{ [-08] = 0 }
{ [-09] = 0 }
SK 2x0E size 1 … 3 SK2x0E size 4
[-01]
Analogue input 1, Function of analogue input 1 integrated into the FI
[-02]
Analogue input 2, Function of analogue input 2 integrated into the FI
[-03]
External Analogue input 1, AIN1 of the first I/O extension (SK xU4-IOE)
[-04]
External Analogue input 2, AIN2 of the first I/O extension (SK xU4-IOE)
[-05]
Setpoint module
[-06]
Digital input 2, can be set to pulse signal
evaluation via P420 [-
02] =26 or 27. The
pulses are then evaluated in the FI as an
analogue signal according to the function
which is set here.
[-06]
Potentiometer 1, Function of the
potentiometer P1 integrated into
the FI. DIP switches 4/5 must be
"Off" so that the function can be
influenced by this parameter
setting (chapter
4.3.2.2)
[-07]
Digital input 3, can be set to pulse signal
evaluation via P420 [-
03] =26 or 27. The
pulses are then evaluated in the FI as an
analogue signal according to the function
which is set here.
[-07]
Potentiometer 2, as for
potentiometer 1
[-08]
External A.in. 1 2nd IOE
, "External analogue input 1 2nd IOE", AIN1 of the second I/O
extension (SK xU4-IOE) (= Analogue input 3)
[-09]
External A.in. 2 2nd IOE, "External analogue input 2 2nd IOE", AIN2 of the second I/O
extension (SK xU4-IOE) (= Analogue input 4)
... Setting values below.
