Power connection
(for power input, power output,
motor output)
AC Power connector for attaching to the device
for making a detachable connection for supply
lines (e.g. mains supply line)
Model SK TIE4-…
 Section 3.2.3.1 "Plug connectors for power
connections"
Control line connection
System connector (M12) for attaching to the
device, for making a detachable connection for
control lines
Model SK TIE4-…
 Section
3.2.3.2 "Plug connectors for control
connection"
Pos: 34 .13 /A nleitu ngen/ Elektr onik /FU und St art er/1. Al lgemei nes/ Liefer umfa ng/Li eferu mfang Zubeh ör_10_ Ada pter [BU 0200] @ 6\ mod_1430917534223_388.docx @ 216118 @ @ 1
Adapter
Adapter cable
Different adapter cables
(
Link)
Mounting Adapter
Different adapter kits for setting up the device on
different motor sizes
 Section
2.1.2.1 "Adapters for different
motors"
Parametrisation adapter
(EEPROM memory module
adapter)
For data backups and parametrising the memory
module (external EEPROM) of the frequency
inverter, independently of the frequency inverter
Type SK EPG-3H
(Link)
Pos: 34 .14 /A nleitu ngen/ Elektr onik /FU und St art er/1. Al lgemei nes/ Liefer umfa ng/Li eferu mfang Zubeh ör_11_ Sonsti ges [ SK 1x0E, SK 2x xE] @ 10\mod_1456150442368_388.docx @ 309760 @ @ 1
Internal electronic brake
rectifier
Customer unit for installing in the device for
direct actuation of an electro-mechanical brake
Model SK CU4-MBR- …
 Section
3.2.1 "Internal customer interfaces
SK CU4-… (installation of modules)"
