Nord Drivesystems NORDAC FLEX SK 210E Series User Manual

5 Parameter
BU 0200 en-3118 213
Pos: 57 9 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P719 – Aktuel ler Str om @ 0\ mod_1328172979998_388.docx @ 12778 @ @ 1
P719
Actual current
(Actual current)
0.0 ... 999.9 A Displays the actual output current.
Pos: 58 0 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P720 – Aktuel ler M omentstrom @ 0\mod_1328173025780_388.docx @ 12801 @ @ 1
P720
Act. torque current
(Actual torque current)
-999.9 ... 999.9 A Displays the actual calculated torque-developing output current (active current).
Basis for
calculation are the motor data P201...P209.
 negative values = generator,  positive values = drive
Pos: 58 1 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P721 – Aktuel ler Fel dstr om @ 0 \mod_1328173074624_388.docx @ 12824 @ @ 1
P721
Actual field current
(Actual field current)
-999.9 ... 999.9 A Displays the actual calculated field current (reactive current). Basis for calculation are the motor
data P201...P209.
Pos: 58 2 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P722 – Aktuelle Spannung @ 0\mod_1328173115169_388.docx @ 12847 @ @ 1
P722
Current voltage
(Actual voltage)
0 ... 500 V Displays the actual AC voltage supplied by the FI output.
Pos: 58 3 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P723 – Aktuelle Spannungskomponente Ud @ 0 \mod_1328173153339_388.docx @ 12870 @ @ 1
P723
Voltage -d
(Actual voltage component Ud)
S
-500 ... 500 V Displays the actual field voltage component.
Pos: 58 4 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par amet er/ Par amet erau fli st ung (P 000 .. .)/P 700- P799 /Par amet er P724 – Aktuelle Spannungskomponente Uq @ 0\mod_1328173194227_388.docx @ 12893 @ @ 1
P724
Voltage -q
(Actual voltage component Uq)
S
-500 ... 500 V Displays the actual torque voltage component.
Pos: 58 5 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P725 – Aktuel ler cos phi @ 0\mod_1328173237475_388.docx @ 12916 @ @ 1
P725
Current Cos phi
(Actual cosj)
0.00 ... 1.00
Displays the actual calculated cos ϕ of the drive.
Pos: 58 6 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P726 – Scheinl eist ung @ 0\mod_1328173288066_388.docx @ 12939 @ @ 1
P726
Apparent power
(Apparent power)
0.00 ... 300.00 kVA
Displays the actual calculated apparent power. The basis for calculation are the motor data
P201...P209.
Pos: 58 7 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P727 – Mechani sc he Leis tung @ 0\mod_1328173332220_388.docx @ 12962 @ @ 1
P727
Mechanical power
(Mechanical power)
-99.99 ... 99.99 kW
Displays the actual calculated effective power of the motor. Basis for calculation are the motor
data P201...P209.
