NORDAC FLEX (SK 200E ... SK 235E) – Users Manual for Frequency Inverters
212 BU 0200 en-3118
Pos: 57 1 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P711 – Zustan d Di git ale Aus gäng e [ SK 2 xxE ] @ 2\ mod_1346932206390_388.docx @ 43536 @ @ 1
P711
State of relays
(state of digital outputs)
00000 ... 11111 (bin)
or
00 ... FF (hex)
Indicates the actual status of the digital outputs of the frequency inverter.
Bit 0 = Digital output 1
Bit 1 = Mechanical brake
Bit 2 = Digital output 2
Bit 3 = reserved
Bit 4 = Digital output 1, IO extension 1
Bit 5 = Digital output 2, IO extension 1
Bit 6 = Digital output 1, IO extension 2
Bit 7 = Digital output 2, IO extension 2
Pos: 57 2 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par amet er/ Par amet erau fli st ung (P 000 .. .)/P 700- P799 /Par amet er P711 – Zu st and D igi tal e Au sg äng e_Tei l2/ 2 [ SK 1 x0E , SK 2x xE, S K 2xxE -FDS] @ 9\ mod_1448448278913_388.docx @ 266811 @ @ 1
Bits 7-4
Bits 3-0
Minimum value
0000
0
0000
0
Binary
hex
Maximum value
1111
F
1111
F
Binary
hex
SimpleBox: The binary bits are converted to a hexadecimal value and displayed.
ParameterBox: The bits are displayed increasing from right to left (binary).
Pos: 57 3 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par amet er/ Par amet erau fli st ung (P 000 .. .)/P 700- P799 /Par amet er P714 – B etri ebs dau er @ 0\ mod_1328172684685_388.docx @ 12663 @ @ 1
P714
Operating time
(Operating time)
0.10 ... ___ h This parameter
shows the time for which the FI was connected to the mains and was ready for
operation.
Pos: 57 4 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P715 – Freigabedauer @ 0\mod_1328172731474_388.docx @ 12686 @ @ 1
P715
Running time
(Enablement time)
0.00 ... ___ h This parameter shows the time for which the FI was enabled and supplied current to the output.
Pos: 57 5 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par amet er/ Par amet erau fli st ung (P 000 .. .)/P 700- P799 /Par amet er P716 – Aktuelle Frequenz @ 0\mod_1328172775215_388.docx @ 12709 @ @ 1
P716
Current frequency
(Actual frequency)
-400.0 ... 400.0 Hz Displays the actual output frequency.
Pos: 57 6 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P717 – Aktuel le Dre hzahl @ 0\ mod_1328172889966_388.docx @ 12732 @ @ 1
P717
Current speed
(Actual rotation speed)
-9999 ... 9999 rpm Displays the actual motor speed calculated by the FI.
Pos: 57 7 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P718 – Aktuel le S oll freq ue nz @ 0\mod_1328172931732_388.docx @ 12755 @ @ 1
P718 [-01]
...
[-03]
Present Actual setpoint
frequency
(Actual setpoint frequency)
-400.0 ... 400.0 Hz Displays the frequency specified by the setpoint
(please see chapter
8.1 "Setpoint processing").
[-01] = Actual setpoint frequency from the setpoint source
[-02] = Actual setpoint frequency after processing in the FI status machine
[-03] = Actual setpoint frequency after frequency ramp
