5 Parameter
BU 0200 en-3118 211
Pos: 56 8 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par amet er/ Par amet erau fli st ung (P 000 .. .)/P 700- P799 /Par amet er P709 – Spannung Analogeingang [SK 2xxE] @ 2\mod_1346932205173_388.docx @ 43488 @ @ 1
P709 [-01]
...
[-09]
Analog input voltage
(Voltage analogue input)
-100 ... 100 % Displays the measured analogue input value.
SK 2x0E SK 2x5E
[-01] = Analogue input 1, function of
analogue input 1 integrated into the FI
[-01] = Potentiometer 1, Internal
potentiometer P1 in the FI
(chapter
4.3.2), for setting the
maximum frequency, minimum
frequency and ramp time
[-02] = Analogue input 2, function of
analogue input 2 integrated into the FI
[-02] = Potentiometer 2, as for
potentiometer 1.
SK 2xxE
[-03] = Ext. analogue input 1, AIN 1 of the first I/O extension SK xU4-IOE
[-04] = Ext. analogue input 2, AIN2 of the first I/O extension SK xU4-IOE
[-05] = Setpoint module, SK SSX-3A, see BU0040
SK 2xxE, size 1 – 3 SK 2x0E, size 4
[-06] = Analogue function Dig. 2, analogue
function of FI digital input 2
[-06] = Potentiometer 1, Internal
potentiometer P1 in the FI
(chapter
4.3.2), for setting the
maximum frequency, minimum
frequency and ramp time
[-07] = Analogue function Dig. 3, analogue
function of FI digital input 3
[-07] = Potentiometer 2, as for
potentiometer 1.
SK 2xxE
[-08] = Ext. A.in. 1 2nd IOE, "External analogue input 1 2nd IOE“, AIN1 of the second
I/O extension (SK xU4-IOE) (= Analogue input 3)
[-09] = Ext. A.in. 2 2nd IOE, "External analogue input 2 2nd IOE“, AIN2 of the second
I/O extension (SK xU4-IOE) (= Analogue input 4)
Pos: 56 9 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P710 – Spannung Analogausgang [SK 1x0E, SK 2xxE, SK 2xxE-FDS] @ 2\ mod_1346932205766_388.docx @ 43512 @ @ 1
P710 [-01]
[-02]
Analogue output volt.
(Analogue output voltage)
0.0 ... 10.0 V Displays the delivered value of analogue output.
[-01] = First IOE, AOUT of the first I/O extension (SK xU4-IOE)
[-02] = Second IOE, AOUT of the second I/O extension (SK xU4-IOE)
