Motor
(IE2)
SK …
Frequency
inverter
SK 2xxE-…
M
N
*
[Nm]
Parameterisation data of frequency inverter
F
N
[Hz]
n
N
[min-1]
I
N
[A]
U
N
[V]
P
N
[kW]
cos ϕ
Y/Δ
R
St
[Ω]
80SH/4
750-340-A
2.44
100
2930
1.9
400
0.75
0.7
Δ
9.34
80LH/4
111-340-A
3.60
100
2920
2.56
400
1.1
0.73
Δ
6.3
90SH/4 151-340-A 4.89 100 2930 3.53 400 1.5 0.79 Δ 4.96
90LH/4
221-340-A
7.18
100
2925
4.98
400
2.2
0.79
Δ
3.27
100LH/4 301-340-A 9.69 100 2955 6.47 400 3.0 0.78 Δ 1.73
100AH/4
401-340-A
13.0
100
2940
8.24
400
4.0
0.79
Δ
1.48
112MH/4
551-340-A
17.8
100
2950
11.13
400
5.5
0.82
Δ
1.0
132SH/4 751-340-A 24.2 100 2960 15.3 400 7.5 0.83 Δ 0.6
132MH/4
112-340-A
29.6
100
2965
19.5
400
9.2
0.79
Δ
0.42
160MH/4 152-340-A 48.3 100 2967 29.0 400 15.0 0.87 Δ 0.256
160LH/4
182-340-A
59.4
100
2975
35.7
400
18.5
0.86
Δ
0.168
180MH/4
222-340-A
70.5
100
2980
43.2
400
22
0.85
Δ
0.115
* at rated point
Motor
(IE3)
SK …
Frequency
inverter
SK 2xxE-…
M
N
*
[Nm]
Parameterisation data of frequency inverter
F
N
[Hz]
n
N
[min-1]
I
N
[A]
U
N
[V]
P
N
[kW]
cos ϕ
Y/Δ
R
St
[Ω]
80SP/4
750-340-A
2.44
100
2935
1.77
400
0.75
0.73
Δ
10.4
80LP/4
111-340-A
3.58
100
2930
2.13
400
1.1
0.84
Δ
6.5
90SP/4
151-340-A
4.86
100
2945
3.1
400
1.5
0.79
Δ
4.16
90LP/4 221-340-A 7.17 100 2930 4.33 400 2.2 0.83 Δ 3.15
100LP/4
301-340-A
9.65
100
2970
5.6
400
3.0
0.85
Δ
1.95
100AP/4
401-340-A
12.9
100
2970
7.42
400
4.0
0.85
Δ
1.58
112MP/4
551-340-A
17.8
100
2950
10.3
400
5.5
0.85
Δ
0.91
132SP/4
751-340-A
24.1
100
2970
14.3
400
7.5
0.83
Δ
0.503
132MP/4 112-340-A 29.6 100 2970 18.0 400 9.2 0.82 Δ 0.381
160SP/4
112-340-A
35.3
100
2975
21.0
400
11.0
0.85
Δ
0.295
160MP/4
152-340-A
48.2
100
2970
27.5
400
15.0
0.86
Δ
0.262
160LP/4
182-340-A
59.4
100
2975
34.4
400
18.5
0.85
Δ
0.169
180MP/4
222-340-A
70.4
100
2985
40.6
400
22.0
0.85
Δ
0.101
* at rated point
