3 Display, operation and options
BU 0200 en-3118 95
Connector (selection)
Type Data Designation Material no. Document
Power input
500 V, 16 A
SK TIE4-HANQ8-K-LE-MX
275 135 030
TI 275135030
Power input
500 V, 16 A
SK TIE4-HAN10E-M1B-LE
275 135 070
TI 275135070
Power input 500 V, 16 A SK TIE4-HAN10E-M2B-LE 275 135 000 TI 275135000
Power input
690 V, 20 A
SK TIE4-QPD_3PE-K-LE
275 274 125
TI 275274125
Power input 630 V, 16 A SK TIE4-NQ16-K-LE 275 274 133 TI 275274133
Power input +
power outlet
400 V, 16 A
SK TIE4-2HANQ5-K-LE-LA
275 274 110
TI 275274110
Power input +
motor outlet
600 V, 16 A
SK TIE4-2HANQ5-M-LE-MA-001
275 274 123
TI 275274123
Power output
500 V, 16 A
SK TIE4-HAN10E-M2B-LA
275 135 010
TI 275135010
Power output
500 V, 16 A
SK TIE4-HANQ8-K-LA-MX
275 135 040
TI 275135040
Motor output
500 V, 16 A
SK TIE4-HAN10E-M2B-MA
275 135 020
TI 275135020
Motor output 500 V, 16 A SK TIE4-HANQ8-K-MA-MX 275 135 050 TI 275135050
Pos: 20 6 /Anlei tung en/El ektr onik/FU und Star ter/1 . Allg emei nes/Sic herh eits- und Ins tall ations hinwei se un d Warn- Gefahrenhinweise/neu/Warn- und Ge fahr enhi nwei se/ Inf ormati on - Durc hschl eife n der Netz spann ung [S K 1xxE, SK2xxE, SK 5xx E] @ 19\mod_1511522397247_388.docx @ 2372439 @ @ 1
Information
Looping of the mains voltage
The permissible current load for the connection terminals, plugs and supply cables must be observed when
looping the mains voltage. Failure to comply with this will result in thermal damage to current-carrying modules
and the immediate vicinity thereof.
