6-12 Routing and terminating the VF cables
AccessNode 323-3001-210 Issue 1.0
Procedure 6-2 (continued)
Connecting the VF cable pairs 1–600 to BIX connectors with the cross-connect
Figure 6-5
Form the second cable with 6–8 inches of slack
—continued—
Tie wrap binder groups and
connectors - form 6–8 inches of
slack toward inside ladder
