6-18 Routing and terminating the VF cables
AccessNode 323-3001-210 Issue 1.0
Procedure 6-4 (continued)
Connecting the VF cable pairs to BIX connectors without the cross-connect
Figure 6-7
Separate 25-pair binder groups from OSP cable
—continued—
Separate binder groups
to appropriate connectors
