Routing and terminating the VF cables 6-21
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 6-4 (continued)
Connecting the VF cable pairs to BIX connectors without the cross-connect
Figure 6-9
Route binder groups to connector pairs 301–550 on the swing frame
—continued—
Route binder groups to
connectors 301-550
Tie wrap binder groups
and connectors - dress
and form slack to inside ladder
To Next Page
