7-22 Routing and splicing the fiber cable
AccessNode 323-3001-210 Issue 1.0
Procedure 7-3 (continued)
Routing the OSP fibers in split flex tubing to the FPP
Special tools required
There are no special tools required for completing this procedure.
Materials required
• spiral wrap tubing (R0116394), approximately 30 feet (9.12 m)
• fiber patch cords (see Table 7-5).
Table 7-5 lists the ordering codes for optical patch cords.
Note: Ensure that the type of connector on the patchcord is compatible
with the type of connectors on the OC-3 or OC-12 card in the ABM shelf
and with the type of connectors in the FPP.
—continued—
Table 7-5
Optical patch cords
PEC
Length
(meters)
Length
(feet) Connector type
Patch cords
NT7E46AA 5 16.4 Biconic-biconic
NT7E46BA 5 16.4 FC-FC
NT7E46CA 5 16.4 ST-ST
Patch cords with miniature optical attenuators
NT7E47AA 5 16.4 Biconic-biconic
NT7E47BA 5 16.4 FC-FC
NT7E47CA 5 16.4 ST-ST
