Routing and splicing the fiber cable 7-23
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 7-3 (continued)
Routing the OSP fibers in split flex tubing to the FPP
Action
Step Action
1 Label each end of the optical patch cords with the following information:
• the slot number in the ABM shelf for the intended OC-3 or OC-12 optical
interface card
• the direction of signal, Tx (transmit) or Rx (receive)
2 Encase the fiber patch cords in protective spiral wrap tubing.
3 Access the rear of the ABM shelf opening the ABM shelf swing frame.
4 Route the protective tubing with the patch cords inside through the cabling
cutout on the hinge side of the rear of the swing frame to the front of the ABM
shelf as shown in Figure 7-10 on page 7-24.
—continued—
To Next Page
