AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
AC load box option
The ac load box option has two 3.00-inch ID openings for 2.00-inch trade size
conduit and a 1.00-inch ID opening for 1.00-inch trade size conduit for
grounding (see Figure 1-1 on page 1-7).
The ac power enters the S800A cabinet via conduit holes located on the bottom
left side of the ac power compartment.
Table 1-5 shows the conduit openings in the ac load box.
Table 1-4
Termination compartment conduit openings
Opening
size
Conduit
trade size Function
4.50 inches
(11.43 cm)
4.00 inches
(10.16 cm)
VF–pairs 1–600 cable entrance
4.50 inches
(11.43 cm)
4.00 inches
(10.16 cm)
VF–pairs 601–1200 cable entrance
4.50 inches
(11.43 cm)
4.00 inches
(10.16 cm)
VF–miscellaneous cable entrance
4.50 inches
(11.43 cm)
4.00 inches
(10.16 cm)
VF–HF or fiber cable entrance
2.00 inches
(5.08 cm)
1.50 inches
(3.81 cm)
Ground-earth ground rod connection entrance
Table 1-5
AC load box conduit openings
Opening
size
Conduit
trade size Function
3.0 inches
(7.62 cm)
2.0 inches
(5.08 cm)
Miscellaneous–dc feed, when required
3.0 inches
(7.62 cm)
2.0 inches
(5.08 cm)
AC entrance–commercial ac feed
1.5 inches
(3.81 cm)
1.0 inches
(2.54 cm)
Ground-earth ground rod connection entrance
