1-6 Installing the pad
AccessNode 323-3001-210 Issue 1.0
AC power pedestal
For cabinets equipped with the optional attached ac power pedestal, there is a
3.50-inch ID opening for 2.50-inch trade size conduit for ac supply and four
2.00-inch ID openings for 1.25-inch trade size conduit for miscellaneous
cabling and grounding as required (see Figure 1-1).
Table 1-6 shows the conduit openings in the ac power pedestal.
Table 1-6
AC power pedestal conduit openings
Opening
size
Conduit
trade size Function
3.50 inches
(8.89 cm)
2.50 inches
(6.35 cm)
AC entrance–commercial ac feed
2.00 inches
(5.08 cm)
1.25 inches
(3.18 cm)
Miscellaneous–dc feed or grounding
2.00 inches
(5.08 cm)
1.25 inches
(3.18 cm)
Miscellaneous–dc feed or grounding
2.00 inches
(5.08 cm)
1.25 inches
(3.18 cm)
Miscellaneous–dc feed or grounding
2.00 inches
(5.08 cm)
1.25 inches
(3.18 cm)
Miscellaneous–dc feed or grounding
