9-6 Installing and connecting the batteries
AccessNode 323-3001-210 Issue 1.0
Procedure 9-1 (continued)
Installing 12 V batteries in a cabinet
Step Action
2 Measure the voltage between the terminals of each new battery pack (see
Table 9-4).
3 Replace any battery pack set that does not meet the requirements in
Table 9-4. See CAUTION 3 on page 9-3.
4 Install, but do not connect, the battery strings. See Table 9-5.
Note:
Each string consists of four 12 V dc battery packs.
—continued—
Table 9-4
Battery voltage check requirements
If the battery type is Then the voltage reading must be
YUASA, 12 V dc ≥11.5 V dc on each 12 V battery
Gates, 12 V dc ≥11.5 V dc on each 12 V battery
Table 9-5
12 V battery string placement in the cabinet
Battery string Placement
1-8 Place at the bottom of the cabinet as shown in
Figure 9-1 on page 9-7.
9-14 Mount on the battery shelves as shown in Figure 9-2
on page 9-8.
