9-10 Installing and connecting the batteries
AccessNode 323-3001-210 Issue 1.0
Procedure 9-1 (continued)
Installing 12 V batteries in a cabinet
Step Action
7 Disconnect all battery harnesses from the battery interface connector field
(see Figure 9-4 on page 9-11). The battery interface connector field is at the
bottom right rear of the rear left swing frame containing the rectifier shelf and
the dc distribution shelf.
8 Connect the batteries installed in step 4 to the connectorized battery harness
at the battery end.
Note:
Each battery harness is labeled to correspond to the correct battery
string.
9 Dress the battery harnesses into the battery compartment (see Figure 9-1 on
page 9-7 and Figure 9-2 on page 9-8). Dress the harnesses between the
batteries so that the cables are secure, free of kinks and twists, and do not
catch or snag on the equipment swing frame as it closes.
10 Check the voltage (-48 V dc) on each connector. The connectors are at the
end of the cable assembly at the battery interface connector field.
Note:
If a connector or battery harness proves faulty (no voltage at the BBP
end), replace the cable assembly and check again for cable integrity.
—continued—
