Nortel SONET AccessNode 800A Series User Manual

Installing and connecting the batteries 9-11
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 9-1 (continued)
Installing 12 V batteries in a cabinet
Figure 9-4
Battery interface connector field on swing frame for 12 V battery cabling
FW-15155
—continued—
Battery
interface
connectors
Battery cables
to strings 1-8
Battery cables
to strings 9-14
14
13
12
11
10
9
8
7
6
5
4
3
2
1
Tie wraps
(4 places)
NT1W64AA
battery interface
cable to battery
breaker panel
Tie wraps
(8 places)
FW-15155
