Installing and connecting the batteries 9-15
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 9-2 (continued)
Installing 6 V batteries in a cabinet
Action
Step Action
1 Turn the battery breaker panel (BBP) circuit breakers to the OFF position for
the battery strings to be installed (see Table 9-7).
2 Measure the voltage between the terminals of each new battery pack (see
Table 9-8).
—continued—
Table 9-7
Battery string circuit breaker assignments for 6 V batteries
If quantity of battery strings
(minimum of three) you are
installing is
Then turn these BBP circuit breakers to the
OFF position
3 BATT 1-2, BATT 3-4, BATT 5-6
4 BATT 1-2, BATT 3-4, BATT 5-6, BATT 7-8
5 BATT 1-2, BATT 3-4, BATT 5-6, BATT 7-8,
BATT 9-10
6 BATT 1-2, BATT 3-4, BATT 5-6, BATT 7-8,
BATT 9-10, BATT 11-12
7 BATT 1-2, BATT 3-4, BATT 5-6, BATT 7-8,
BATT 9-10, BATT 11-12, BATT 13-14
Table 9-8
6 V battery voltage check requirements
If the battery type is Then the voltage reading must be
Eagle-Picher, 6 V dc ≥ 5.75 V dc on each 6 V battery
