9-18 Installing and connecting the batteries
AccessNode 323-3001-210 Issue 1.0
Procedure 9-2 (continued)
Installing 6 V batteries in a cabinet
Figure 9-7
P0749332 battery harness adapter for use with 6 V batteries
FW-15748
—continued—
FW-15748
2- position female Mate-N-Lok
connectors (to 6 V batteries)
2- position male Mate-N-Lok
connector (to P0731360-63
12 V battery cable harnesses)
