Nortel SONET AccessNode 800A Series User Manual

Installing and connecting the batteries 9-17
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 9-2 (continued)
Installing 6 V batteries in a cabinet
Figure 9-6
Battery string (1-4) arrangement for 6 V batteries on the cabinet floor
FW-15151
—continued—
Note 1: String 2 and string 4 require special battery orientation for 6 V Eagle-Picher batteries.
Some batteries must be installed in an “on-the-side” orientation (see Figure 9-8 on
page 9-19).
Note 2: 6 V batteries in the 800A cabinet also require a P0749332 battery harness adapter
(see Figure 9-7 on page 9-18)
REAR
FRONT
1A 1B
1C 1D
1E
1F
1G
1H
2A 2B
2C 2D
2E
2F
2G
2H
4A
4B
4C
4D 4E
4F
4G
4H
3E
3F
3G
3H
String 1
Battery harness 1
P0731360
String 2 (see note)
Battery harness 2
P0731361
To
battery
interface
connector
field
Battery harness 4
P0731363
String 4 (see note)
Battery harness 3
P0731362
String 3
FW-15151
3A
3B
3C
3D
- + - +
+ - + -
- + - +
+ - + -
- + - +
+ - + -
- + - +
+ - + -
- + - +
+ - + -
- + - +
+ -+ - + -
- + - +
+ -
- + - +
+ - + -
