Installing and connecting the batteries 9-25
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 9-2 (continued)
Installing 6 V batteries in a cabinet
Step Action
12 Connect the battery string cable assemblies to the corresponding connector
on the battery interface connector field (see Figure 9-11 on page 9-23).
Note 1:
The battery string numbers are labeled on each battery harness to
correspond to the connections on the BBP adapter.
Note 2:
If the number of battery strings (minimum of three) to be installed is
3, 4 or 5, then each battery string must be connected to an odd numbered
battery interface connector field position (1, 3, 5, 7 and 9). The even
numbered connector positions (2, 4, 6, 8 and 10) must be insulated
(completely covered) with heat-shrinkable tubing.
13 Turn circuit breakers BATT 1-2 through BATT 13–14 to the On position on the
BBP. See Table 9-10.
—end—
Table 9-10
Battery string circuit breaker assignments for 6 V batteries
If quantity of battery strings
you have installed is
Then connect the battery strings
(in sequence)
to battery interface connector positions
3 1, 3, 5
4 1, 3, 5, 7
5 1, 3, 5, 7, 9
6 1, 3, 5, 7, 9, 11
7 1, 3, 5, 7, 9, 11, 13
