1-12 Installing the pad
AccessNode 323-3001-210 Issue 1.0
Procedure 1-1 (continued)
Preparing the poured-in-place cabinet mounting pad
Figure 1-4
Load box, flat, wide concrete pad (reference drawing P0743184)
FW-15103
—continued—
90.00 in.
130.00 in.
End view
(228.60 cm)
(330.20 cm)
FW-15103
Flat
surface
Sloped surface
all around
30.00 in.
(76.20 cm)
29.00 in.
(73.66 cm)
7.00 in. (17.78 cm) prefabricated
(6.00 in. or 15.24 cm) poured in place
