12-8 Cabinet maintenance operations
AccessNode 323-3001-210 Issue 1.0
Procedure 12-1 (continued)
Replacing the batteries
Action
Step Action
1 Turn the battery breaker panel (BBP) circuit breaker for the battery string(s)
to be replaced to the OFF position (see Table 12-3).
—continued—
Table 12-3
Battery string circuit breaker assignments
If quantity of battery strings
(minimum of three)
you are going to install is
Then turn these BBP circuit
breakers to the
OFF position
3 A1, A2, A3
4 A1, A2, A3, A4
5 A1, A2, A3, A4, A5
6 A1, A2, A3
7 A1, A2, A3, A4
8 A1, A2, A3, A4
9 A1, A2, A3, A4, B2
10 A1, A2, A3, A4, B2
11 A1, A2, A3, A4, B2, B3
12 A1, A2, A3, A4, B2, B3
13 A1, A2, A3, A4, B2, B3, B4
14 A1, A2, A3, A4, B2, B3, B4
