Installing the pad 1-15
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 1-1 (continued)
Preparing the poured-in-place cabinet mounting pad
Figure 1-7
Power pedestal (ac), elevated, narrow concrete pad (reference drawing P0729559)
FW-15106
—continued—
50.00 in.
(127.00 cm)
10.00 in.
(25.40 cm)
80.00 in.
(203.20 cm)
End View
4.00 in.
(10.16 cm)
6.00 in.
(15.24 cm)
32.00 in.
(81.28 cm)
9.00 in.
(22.86 cm)
100.00 in.
(250.54 cm)
FW-15106
